DEHNcap/PC-LRM Phase Comparator

Easy and safe testing

DEHNcap/PC-LRM

1 Prodotto

GTIN (EAN) 4013364073005, Codice doganale (EU): 90303320, Peso lordo: 720.00 g, UM: 1.00 pc(s)

Immagini

Maggior informazioni

Certificati

Caratteristiche tecniche

Dimensions	145 x 85 x 32 mm
Measuring cables	3 measuring cables with multilam plug (Ø4 mm)
Length (measuring cable)	2000 mm
Indication threshold (LRM system)	5 V
Input impedance (LRM system)	2 MOhms

Nominal voltage (U_N )	1 ... 45 kV
Dimensions	145 x 85 x 32 mm
Measuring cables	3 measuring cables with multilam plug (Ø4 mm)
Length (measuring cable)	2000 mm
Indication threshold (LRM system)	5 V
Input impedance (LRM system)	2 MOhms
Standard	EN/IEC 61243-5 (DIN VDE 0682-415)
Temperature range	–25 °C ... +55 °C
Type of device	Phase comparator
Design	Active indicator for verifying in-phase conditions on LRM test sockets
Use	For LRM test sockets with two HR-LRM test adapters
Indication	Visual
Type of system	LRM
Self-testing element	Yes

Apri blocco note

Apri Web-Shop

Phase comparator in an artificial leather bag (KLT 23 164).
